2.54mm 26P 64P Card Edge To Card Edge connector Flat Ribbon cable assembly
Part No.：B2426AG0650B01
Conn Spec.: 2.54mm 26P 64P Card Edge To Card Edge connector Flat Ribbon cable assembly,
UL2651 28AWG,Custom Cable lengths.
Options: 10P 14P 16P 20P 26P 34P 40P 50P 60P 64P
Packing:Tray/PE.Bag Packing
Delivery Time:10~15Days
• IDC/IDT Flat Cable for Board intermating connections
• Wide variety of plating thickness for connectors options
• Various cable lengths, shielding, crimp connectors options
• Multiple Header connectors mating design are available
• Wire gauges, jackets, latch and custom markings are available.
----------------------------------------------------------------------------------------------------------------------------------------------
SPECIFICATIONS
• Current Rating: 1.0 AMP
• Contacts Resistance: 20 Mega ohms Min.
• Withstand Voltage: 500V AC/DC
• Insulation Resistance: 1000 Mega ohms Min.
• Contact Material: Phosphor Bronze
• Contact Plating:Selective Gold Plating over Nickel with Tin Plated Tails
• Insulator Material: Polyester(UL94V-0)
• Standard: PBT
• Operating Temperature: -40°C to +105°C
----------------------------------------------------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------
DONGGUAN HONSHI ELECTRONICS CO.,LTD, Welocme to inquiry Multilam plugs Contact series!
Main research and development,production,sales: Machined Pin,Pogo Pin,Spring-Loaded Pin,Pogo pin connector,Connectors PIN,
magnetic charging connector, wire connector,precision automatic lathe parts,military special connector,lead-free halogen-free
precision connectors and other electronic product parts.
How to order:
1) Can design drawings and optimize structures according to customer needs.
2) Customized processing based on drawings and samples, with free samples available in stock.
3) High precision CNC automatic lathe ensures product processing accuracy.
2. We will offer our best price for you.
3. After you confirmed the price,we start to prepare the sample(usually within one week)
4. After you confirmed the sample,you place an order.(you can T/T,or pay to our Paypal)
